Absolute Encoder (Auxiliary)

The controller retrieves absolute position data along with encoder fault information through a serial data stream from the absolute encoder. Use twisted-pair wiring for the highest performance and noise immunity. You cannot use an absolute encoder with incremental signals on the Aux Encoder Connector.

Refer to Absolute Encoder Schematic (Aux Encoder Connector) for the serial data stream interface.

For information on how to set up your auxiliary EnDat, BiSS, or SSI absolute encoder parameters, refer to Automation1 Help.

Table 2-41: Absolute Encoder Specifications

Specification	Value
Sampling Frequency	20 kHz
Maximum Reading Speed	Refer to your encoder data sheet.

Figure 2-40: Absolute Encoder Schematic (Aux Encoder Connector)
