Analog Inputs (Differential)
To interface to a single-ended, non-differential voltage source, connect the signal common of the source to the negative input and connect the analog source signal to the positive input. A floating signal source must be referenced to the analog common. Refer to Analog Inputs Schematic.
Table 2-38: Analog Input Specifications
|
Specification |
Value |
|---|---|
|
(AI+) - (AI-) |
+10 V to -10 V (1) |
|
Resolution (bits) |
16 bits |
| Input Impedance | 50 kΩ |
|
1. Signals outside of this range may damage the input |
|
Table 2-39: Analog Input Pins on the Analog I/O and Laser Interface Connector
|
Pin # |
Description |
In/Out/Bi |
|---|---|---|
| 6 | Analog Common | Output |
| 7 | Analog Input 0+ (Differential) | Input |
| 17 | Analog Input 0- (Differential) | Input |
| 8 | Analog Input 1+ (Differential) | Input |
| 18 | Analog Input 1- (Differential) | Input |
| 9 | Analog Input 2+ (Differential) | Input |
| 19 | Analog Input 2- (Differential) | Input |
| 10 | Analog Input 3+ (Differential) | Input |
| 20 | Analog Input 3- (Differential) | Input |
Figure 2-31: Analog Inputs Schematic
