Handwheel Interface
A handwheel can be used to manually control axis position. The handwheel must provide 5V differential quadrature signals to the
IMPORTANT: You can find instructions on how to enable the handwheel in the online Help file.
Connect a handwheel to the Aux I/O as shown in Handwheel Interconnection to Aux I/O Connector or Handwheel Interconnection to the Aux I/O through a BBA32 Module.
Figure 4-3: Handwheel Interconnection to Aux I/O Connector
Figure 4-4: Handwheel Interconnection to the Aux I/O through a BBA32 Module
